EVRL red and violet handheld pain laser device

EVRL Laser

Erchonia’s red & violet handheld laser, the EVRL. Since its release has become our most popular handheld device by offering the versatility of a red and violet wavelength taking outcomes to a whole new level. By combining these two specific wavelengths into one treatment modality, patients received better results during clinical studies then the dual red and opened up a new range of treatment conditions stimulating complexes 1, 2 & 4! The violet is also shown to be effective with its anti-bacterial & anti-microbial properties.

Indications for Use: – K152196
The Erchonia® EVRL laser is generally indicated:
a. while using the red diode, for adjunctive use in providing temporary relief of minor chronic neck and shoulder pain of musculoskeletal origin,
b. and while using the violet diode, to treat dermatological conditions, and specifically indicated to treat moderate inflammatory Acne Vulgaris.

*Device intended for Medical Professionals
*Prescription Use (Part 21 CFR 801 Subpart D)

Product Description

The exceptional versatility of this violet and red laser pain treatment allows doctors, chiropractors, physical therapists and other medical professionals to target a broader range of conditions with a single, easy-to-use device. With exceptional clinical research and FDA market clearance. EVRL lasers are a trusted and proven treatment approach, allowing practitioners to change patients’ lives without the harmful side effects associated with traditional treatment options.

EVRL red and violet laser treatment on a person's shoulder to treat pain

How it Works

Erchonia uses low level lasers in the visible light spectrum. The primary mechanism for the absorption of visible light photons is the elevation of electrons to higher energy levels. This is known as molecular excitement and can be explained deeper through visible/ UV Spectroscopy.

Visible light photons match the energy volt (eV) or frequency between the orbits of electrons to move the electron to a higher state (excite). It is in this excited state that chemical reactions of molecules occur. One of the most important chemical reactions is when photons of visible light energy strike certain atoms, that energy may push an electron to a higher energy level where it can be picked up by an electron acceptor. The electron transport chain uses the high-energy electrons to convert ADP into ATP. The electron transport chain (ETC) is the primary source of ATP production in the body and is vital for life!

Specifications

  • Configuration: (1) 7.5 mW Line Generated Red Laser Diode, (1)
  • 7.5mW Line Generated Violet Laser Diode with Patented Optics
  • Wavelength: 640nm & 405nm
  • Modulation: Constant Wave (CW) & Pulsed (Hz)
  • 100 User Defined Memory Channels
  • 1 Preset Protocol Channels
  • Display: Full Color TFT Touchscreen Technology for Ease of Use
  • Power Source: 3.7 VDC Lithium-ion Polymer Battery
  • Enclosure: Micro-Textured Anodized Aircraft Aluminum for Strength and Ease of Cleaning
  • Weight: 0.95lbs (.42 kg) (Device Only)
  • Compliant to ISO 13485 Medical Device Quality, ISO 14971 Risk Management, IEC 60601-1 Safety, 60601-1-2 EMC, IEC 60825-1 Laser Safety
  • Laser Class 2 / Device Class ll (USA); IIa (EU)
